A Coding Implementation on kvcached for Elastic KV Cache Memory, Bursty LLM Serving, and Multi-Model GPU Sharing

import os, sys, time, json, subprocess, threading, signal, shutil
from pathlib import Path


def sh(cmd, check=True):
return subprocess.run(cmd, check=check, shell=isinstance(cmd, str))


try:
import torch
except ImportError:
sh([sys.executable, "-m", "pip", "install", "-q", "torch"])
import torch


assert torch.cuda.is_available(), \
"No GPU detected. In Colab: Runtime > Change runtime type > GPU."
props = torch.cuda.get_device_properties(0)
print(f"[GPU] {torch.cuda.get_device_name(0)} "
f"({props.total_memory / 1e9:.1f} GB, "
f"compute capability {props.major}.{props.minor})")


def pip_install(*pkgs, extra=()):
subprocess.run([sys.executable, "-m", "pip", "install", "-q", *pkgs, *extra],
check=True)


print("[install] vLLM ...")
pip_install("vllm==0.10.2")
print("[install] kvcached (compiles a small CUDA extension) ...")
pip_install("kvcached", extra=["--no-build-isolation"])
print("[install] misc (matplotlib, requests, pynvml) ...")
pip_install("matplotlib", "requests", "pynvml", "numpy")


MODEL_A = "Qwen/Qwen2.5-0.5B-Instruct"
MODEL_B = "Qwen/Qwen2.5-1.5B-Instruct"
PORT_A, PORT_B = 8001, 8002
MAX_MODEL_LEN = 2048

def launch_vllm(model, port, kvcached=True, gpu_mem_util=0.55, log_path=None):
"""Start a vLLM OpenAI-compatible server as a subprocess. With kvcached=True
the autopatch hooks replace vLLM's KV-cache allocator with the elastic one."""
env = os.environ.copy()
env["VLLM_USE_V1"] = "1"
if kvcached:
env["ENABLE_KVCACHED"] = "true"
env["KVCACHED_AUTOPATCH"] = "1"
env["KVCACHED_IPC_NAME"] = f"kvc_{port}"
cmd = [
sys.executable, "-m", "vllm.entrypoints.openai.api_server",
"--model", model, "--port", str(port),
"--max-model-len", str(MAX_MODEL_LEN),
"--disable-log-requests",
"--no-enable-prefix-caching",
"--enforce-eager",
]
if not kvcached:
cmd += ["--gpu-memory-utilization", str(gpu_mem_util)]
log = open(log_path or os.devnull, "w")
proc = subprocess.Popen(cmd, env=env, stdout=log, stderr=subprocess.STDOUT,
preexec_fn=os.setsid)
return proc, log


def wait_ready(port, timeout=420):
import requests
url = f"http://localhost:{port}/v1/models"
t0 = time.time()
while time.time() - t0 < timeout:
try:
if requests.get(url, timeout=2).status_code == 200:
return True
except Exception:
pass
time.sleep(3)
raise TimeoutError(f"vLLM on port {port} didn't come up within {timeout}s")


def shutdown(proc, log):
if proc and proc.poll() is None:
try:
os.killpg(os.getpgid(proc.pid), signal.SIGTERM)
proc.wait(timeout=45)
except Exception:
os.killpg(os.getpgid(proc.pid), signal.SIGKILL)
if log and not log.closed:
log.close()
time.sleep(3)

import pynvml
pynvml.nvmlInit()
NV_HANDLE = pynvml.nvmlDeviceGetHandleByIndex(0)


def vram_used_mb():
info = pynvml.nvmlDeviceGetMemoryInfo(NV_HANDLE)
return info.used / (1024 ** 2)


class MemorySampler(threading.Thread):
def __init__(self, interval=0.2):
super().__init__(daemon=True)
self.interval = interval
self.samples = []
self._stop = threading.Event()
def run(self):
t0 = time.time()
while not self._stop.is_set():
self.samples.append((time.time() - t0, vram_used_mb()))
time.sleep(self.interval)
def stop(self):
self._stop.set(); self.join()


import requests
from concurrent.futures import ThreadPoolExecutor


PROMPTS = [
"Explain quantum entanglement to a curious 10-year-old.",
"Write a Python function that detects cycles in a linked list.",
"Summarize the plot of Hamlet in one paragraph.",
"List 5 surprising household uses for baking soda with explanations.",
"Compose a vivid haiku about rainy Monday mornings.",
"Describe the Fermi paradox and three plausible resolutions.",
"Translate 'knowledge is power' into French, German, and Japanese.",
"Explain the difference between TCP and UDP with real examples.",
]


def bursty_workload(port, model, n_bursts=3, burst_size=6, pause=6.0,
max_tokens=180):
"""Fire n_bursts waves of burst_size concurrent requests with an idle
gap between waves. The idle gap is where kvcached releases physical
VRAM -- a static-allocation engine simply cannot."""
url = f"http://localhost:{port}/v1/chat/completions"
def one(i):
body = {
"model": model,
"messages": [{"role": "user", "content": PROMPTS[i % len(PROMPTS)]}],
"max_tokens": max_tokens, "temperature": 0.7,
}
t0 = time.time()
r = requests.post(url, json=body, timeout=180)
r.raise_for_status()
return time.time() - t0
latencies = []
with ThreadPoolExecutor(max_workers=burst_size) as ex:
for b in range(n_bursts):
print(f" burst {b+1}/{n_bursts} ({burst_size} concurrent)")
latencies += list(ex.map(one, range(burst_size)))
if b < n_bursts - 1:
time.sleep(pause)
return latencies

print("\n=== Experiment 1: vLLM + kvcached ===")
proc, log = launch_vllm(MODEL_A, PORT_A, kvcached=True,
log_path="/tmp/vllm_kvc.log")
try:
wait_ready(PORT_A)
idle_kvc = vram_used_mb()
print(f" Idle VRAM after load (weights only): {idle_kvc:.0f} MB")
sampler = MemorySampler(); sampler.start()
lat_kvc = bursty_workload(PORT_A, MODEL_A)
time.sleep(6)
sampler.stop()
mem_kvc = sampler.samples
finally:
shutdown(proc, log)


print("\n=== Experiment 2: vLLM baseline (static KV allocation) ===")
proc, log = launch_vllm(MODEL_A, PORT_A, kvcached=False,
log_path="/tmp/vllm_base.log")
try:
wait_ready(PORT_A)
idle_base = vram_used_mb()
print(f" Idle VRAM (weights + pre-reserved KV pool): {idle_base:.0f} MB")
sampler = MemorySampler(); sampler.start()
lat_base = bursty_workload(PORT_A, MODEL_A)
time.sleep(6)
sampler.stop()
mem_base = sampler.samples
finally:
shutdown(proc, log)

import numpy as np
import matplotlib.pyplot as plt


fig, axes = plt.subplots(1, 2, figsize=(14, 4.5))


tk, mk = zip(*mem_kvc); tb, mb = zip(*mem_base)
axes[0].plot(tk, mk, label="with kvcached", linewidth=2, color="#1f77b4")
axes[0].plot(tb, mb, label="baseline (static)", linewidth=2,
linestyle="--", color="#d62728")
axes[0].axhline(idle_kvc, color="#1f77b4", alpha=.3, linestyle=":")
axes[0].axhline(idle_base, color="#d62728", alpha=.3, linestyle=":")
axes[0].set_xlabel("time (s)"); axes[0].set_ylabel("GPU memory used (MB)")
axes[0].set_title("VRAM under a bursty workload\n(dotted = idle-baseline VRAM)")
axes[0].grid(alpha=.3); axes[0].legend()


axes[1].boxplot([lat_kvc, lat_base], labels=["kvcached", "baseline"])
axes[1].set_ylabel("request latency (s)")
axes[1].set_title(f"Latency across {len(lat_kvc)} requests")
axes[1].grid(alpha=.3)


plt.tight_layout()
plt.savefig("/content/kvcached_single_model.png", dpi=120, bbox_inches="tight")
plt.show()


print("\n--- Single-model summary --------------------------------------------")
print(f" Idle VRAM kvcached: {idle_kvc:>6.0f} MB "
f"baseline: {idle_base:>6.0f} MB "
f"(savings: {idle_base - idle_kvc:>5.0f} MB)")
print(f" Peak VRAM kvcached: {max(mk):>6.0f} MB "
f"baseline: {max(mb):>6.0f} MB")
print(f" Median lat. kvcached: {np.median(lat_kvc):>6.2f} s "
f"baseline: {np.median(lat_base):>6.2f} s")
print(f" VRAM flex kvcached: peak-idle = {max(mk)-min(mk):>5.0f} MB "
f"(baseline can't release -- static pool)")


print("\n=== Experiment 3: Two LLMs sharing one GPU (kvcached on both) ===")
pA, lA = launch_vllm(MODEL_A, PORT_A, kvcached=True, log_path="/tmp/mA.log")
try:
wait_ready(PORT_A)
pB, lB = launch_vllm(MODEL_B, PORT_B, kvcached=True, log_path="/tmp/mB.log")
try:
wait_ready(PORT_B)
print(f" Both models loaded. Idle VRAM: {vram_used_mb():.0f} MB")


sampler = MemorySampler(); sampler.start()
for i in range(4):
port, model = ((PORT_A, MODEL_A) if i % 2 == 0
else (PORT_B, MODEL_B))
print(f" round {i+1}: driving {model}")
bursty_workload(port, model, n_bursts=1, burst_size=4, pause=0)
time.sleep(5)
sampler.stop()
t, m = zip(*sampler.samples)


plt.figure(figsize=(11, 4.2))
plt.plot(t, m, color="#c2410c", linewidth=2)
plt.xlabel("time (s)"); plt.ylabel("GPU memory used (MB)")
plt.title("Two LLMs on one T4 via kvcached — memory flexes per active model")
plt.grid(alpha=.3); plt.tight_layout()
plt.savefig("/content/kvcached_multillm.png", dpi=120,
bbox_inches="tight")
plt.show()
finally:
shutdown(pB, lB)
finally:
shutdown(pA, lA)


print("\n=== Bonus: kvcached ships CLI tools ===")
print(" kvtop — live per-instance KV memory monitor (like nvtop for kvcached)")
print(" kvctl — set/limit per-instance memory budgets in shared memory")
for tool in ("kvtop", "kvctl"):
path = shutil.which(tool)
print(f" {tool}: {path or 'not on PATH'}")
print("\nAll plots saved to /content/. Done.")
